High Efficiency Flexible Solar Panel Black Flexible Panel Solar 100W

High Efficiency Flexible Solar Panel Black Flexible Panel Solar 100W

Product Description

1. Monocrystalline silicon solar panel: Monocrystalline silicon solar panel is one of the most common solar panels. It is made of monocrystalline silicon with high efficiency and excellent performance. Monocrystalline silicon solar panels are usually blue or black, with long service life, but high cost.
2. Polysilicon solar panel: polysilicon solar panel is made of polysilicon, its efficiency is slightly lower than monocrystalline silicon solar panel, but its cost is lower. The battery panel is usually dark blue or black
3. Organic solar panels: Organic solar panels are made of organic materials, with lower efficiency than other solar panels, but lower cost. These panels are usually brown or gray

Product Feature

1)High power output
Up to 540W front power and 21.1% module efficiency with half-cut and
 (Multi Busbar) technology bringing more BOS savings
• Lower resistance of half-cut and good reection eect of  ensure highpower
2)High reliability
• Ensured PID resistance through cell process and module material control
• Resistant to salt, acid and ammonia
• Certified to 5400 Pa positive load and 2400 Pa negative load
3)High energy generation
• Excellent IAM and low light performance validated
process and module material optimization
• Lower temp coefficient (-0.36%) and bring more energy leading to
lower LCOE
• Better anti-shading performance and lower operating temperature
4)lower hot spots
Reduce the hot spots and minimize panel degradation

Product Application

Product Advantages

 Product Specifications

Maximum Power (Pmax)    100W
Maximum Power Voltage 20.23V
Maximum Power Current    4.96A
Open Circuit Voltage    24.31V
Short Circuit Current    5.22A
Power Tolerance    0~+5
Weight    1.55Kg
Module  Dimension    1065×520×1.4mm
Maximum System Voltage
