5KW All-In-One Home Energy Storage Battery 3.2KW Built-In Hybrid Inverter 51.2V 100Ah LiFePO4 Battery

5KW All-In-One Home Energy Storage Battery 3.2KW Built-In Hybrid Inverter 51.2V 100Ah LiFePO4 Battery

Product Description

An inverter is a power electronics device that can convert direct current (DC) electrical energy into alternating current (AC) electrical energy. It changes the voltage, frequency, and phase of the input power supply by controlling current and voltage, thereby achieving power conversion.

Product Advantages

Inverters allow DC devices to use AC power. An inverter converts DC power to AC power, which means DC devices can run on mains (AC) power without having to replace the power supply.
Inverters save energy. Inverters save energy by converting DC power sources like solar panels into AC power. It can also use other DC sources, such as car batteries, to provide temporary power during a power outage.
Inverters can increase the flexibility and mobility of equipment. Since an inverter converts DC power to AC power, it is easy to move equipment to different locations regardless of whether AC power is available at that location.
Inverters can improve power quality. Inverters filter out clutter and voltage spikes in the power supply, providing more stable, cleaner power.
Inverters protect electronic equipment. Inverters can provide the stable power required by electronic equipment, thereby reducing the risk of damage to electronic equipment.

Product Display



Product Categories

Inverter based on pulse width modulation (PWM): Controls the output voltage by changing the voltage and frequency of the input power source, usually used to drive AC motors or power household appliances.
Inverters based on multi-level output: improve the quality and efficiency of the output voltage by outputting multiple levels of voltage, and are usually used in fields such as industrial control and solar power generation.
Inverter based on resonance technology: The conversion of electric energy is realized by connecting the power supply and load in series with a resonance circuit. It has the characteristics of high efficiency, high frequency and low noise, and is usually used in high-end power applications, such as medical equipment and high-speed trains.

Product Specifications

Battery System Battery Type LiFePO4
  Voltage 51.2 V
  Nominal Capacity (40°C , 0.5C) 100 Ah
  Energy 5120Wh
Inverter Waveform Pure Sine wave
  Spec 3.2KVA 48V
  Grid type Hybrid/Off grid, option
  Rated output power 3200W
  Normal output voltage 220/230/240VAC/110V
  Frequency 50/60HZ
  Efficiency ≥92%
  Normal output current 14A
  Max AC charge current 60A (Optional 10A to 60A)
  Controller MPPT
Solar Panel Max PV array power 5000W
  PV operating voltage range 120-450VDC
Operation temperature   0-50℃
Communication   WIFI, APP
Dimension (L*W*H mm) 710*300*600mm
Weight Net Weight 74KG
