Photovoltaic Solar Power Inverter 2kw 3kw 4kw 5kw 10kw Grid Tie inverter With Mppt

Product Description

An inverter is a power electronics device that can convert direct current (DC) electrical energy into alternating current (AC) electrical energy. It changes the voltage, frequency, and phase of the input power supply by controlling current and voltage, thereby achieving power conversion.

Product Advantages

Inverters allow DC devices to use AC power. An inverter converts DC power to AC power, which means DC devices can run on mains (AC) power without having to replace the power supply.
Inverters save energy. Inverters save energy by converting DC power sources like solar panels into AC power. It can also use other DC sources, such as car batteries, to provide temporary power during a power outage.
Inverters can increase the flexibility and mobility of equipment. Since an inverter converts DC power to AC power, it is easy to move equipment to different locations regardless of whether AC power is available at that location.
Inverters can improve power quality. Inverters filter out clutter and voltage spikes in the power supply, providing more stable, cleaner power.
Inverters protect electronic equipment. Inverters can provide the stable power required by electronic equipment, thereby reducing the risk of damage to electronic equipment.

Product Display



Product Features
Max eficiency to 98%.
Wide input voltage range . high eficient MPPT.
Multiple inverters can be operated in parallel.
W ithout insulated transfomer . strong IP65 protection.
Small and light , easy to installtion .
LCD display.
Flexible monitoring mode, support RS232/RS485, WIFI/GPRS.
Protection Function
DC polarity reverse connection protection, Anti-island ,input
overvoltage，output overcurrent, output short circuit， overheat,
overload, ground fault, grid overoltage/low voltage, grid high/low
frequency, grid monitoring, RCD testing.

Product Categories

Inverter based on pulse width modulation (PWM): Controls the output voltage by changing the voltage and frequency of the input power source, usually used to drive AC motors or power household appliances.
Inverters based on multi-level output: improve the quality and efficiency of the output voltage by outputting multiple levels of voltage, and are usually used in fields such as industrial control and solar power generation.
Inverter based on resonance technology: The conversion of electric energy is realized by connecting the power supply and load in series with a resonance circuit. It has the characteristics of high efficiency, high frequency and low noise, and is usually used in high-end power applications, such as medical equipment and high-speed trains.

Product Specifications

Input Voltage：100-450VDC	Output Voltage:230VAC
Output Current:26A	Output Frequency:50Hz/60Hz
Output Type:Single	Size:405*415*190mm
Type:DC/AC Inverters	Inverter Efficiency:93%
Certificate:CE	Weight:22kg
MPPT tracking voltage:1/2	Communication Interface:10900W
Maz DC Input Current:13A/26A/28A/50A	Frequency:50hz/60hz
MPPT Tracking Voltage Range:100-450VDC	Power off/on voltage:100V/200VDC
Rated power:3000W/5000W/6000W	Output Volgtage Range:190-270VAC
